Eversolo DMP-A8 Master Edition Gen 2
High-End Music Streamer, Dac, Cd Player & Analog Preamplifier
The Eversolo DMP-A8 Master Edition Gen 2 is a reference-class digital audio hub designed for demanding music systems where streaming, high-resolution digital playback, physical CD playback and high-quality analog preamplification need to work together in one sophisticated component.
Building on the DMP-A8 Gen 2 platform, the Master Edition adds an OCXO precision clock with PLL technology, femtosecond-level system timing, 10 MHz external clock input, enhanced electrical isolation and a dedicated custom CD playback system. Combined with the AKM AK4191EQ + AK4499EXEQ DAC architecture, R-2R analog volume control and fully balanced preamplifier stage, it is engineered for exceptional resolution, timing accuracy and system-level integration.
Flagship Digital Audio Architecture
At the heart of the DMP-A8 Master Edition Gen 2 is the AK4191EQ digital processor paired with the AK4499EXEQ DAC, providing a highly refined signal path capable of decoding up to DSD512 Native and PCM 768kHz/32-bit.
Eversolo's AuralEngine processing platform works alongside the DAC architecture to preserve musical detail, imaging and tonal accuracy while maintaining an exceptionally clean background. The result is a presentation designed to reveal subtle information without becoming analytical or mechanical.
Master Edition Clock Precision
The Master Edition Gen 2 is distinguished by its advanced clocking architecture. An OCXO crystal oscillator with PLL technology provides a highly stable timing reference, reducing the influence of temperature variation and improving clock precision throughout the digital signal chain.
For advanced systems, the unit also supports a 10 MHz external clock input, allowing integration with a dedicated master clock for even more precise system synchronization.
Integrated Cd Playback
The Master Edition introduces a custom top-loading CD playback system designed specifically for high-quality audio applications.
The mechanism is optimized for reading stability, error correction and operational noise control, helping minimize mechanical vibration and unwanted interference during playback. It brings physical CD collections into the same high-resolution environment as network streaming and digital sources.
Precision R-2r Volume Control
Instead of relying solely on conventional digital attenuation, the DMP-A8 Master Edition Gen 2 employs a high-precision R-2R resistor ladder for analog-domain volume adjustment.
This architecture is designed to preserve dynamics and detail throughout the volume range while working with the fully balanced analog preamplifier stage for precise system control.
Fully Balanced Preamplifier
The DMP-A8 Master Edition Gen 2 combines digital source management with a serious analog preamplifier section.
Balanced XLR and single-ended RCA analog inputs allow direct connection of external analog sources, while XLR and RCA preamp outputs provide flexible integration with power amplifiers, active speakers and other audio systems. The analog input stage supports up to +10dB gain.
Comprehensive Digital Connectivity
The DMP-A8 Master Edition Gen 2 is designed to function as the central digital hub of a modern high-end system.
Connectivity includes
-
HDMI ARC/eARC for high-quality audio from compatible TVs and projectors.
-
USB-B audio input for computers and compatible digital sources.
-
USB audio output for connection to external DACs.
-
IIS output with multiple configurable modes.
-
AES/EBU professional digital output.
-
Optical and coaxial digital inputs and outputs.
-
Dedicated subwoofer output.
-
XLR and RCA analog inputs and outputs.
-
Gigabit Ethernet.
-
Wi-Fi 6.
-
SFP optical networking for electrically isolated network transmission.
-
Bluetooth 5.4.
High-Resolution Music Support
It supports major lossless formats and integrates streaming platforms and network playback technologies including TIDAL, Qobuz, HIGHRESAUDIO, Amazon Music, Apple Music, Deezer, Spotify Connect Lossless, TIDAL Connect, Qobuz Connect, DLNA and more.
Wi-Fi 6 & Sfp Networking
Dual-band Wi-Fi 6 provides fast and stable wireless networking, while the dedicated SFP optical network interface offers an electrically isolated connection for systems where network noise and interference are important considerations.
The SFP interface supports compatible gigabit single-mode optical modules, which are purchased separately.
Expandable Music Storage
An internal M.2 NVMe PCIe 3.0 2280 slot allows storage expansion of up to 8TB.
This makes the DMP-A8 Master Edition Gen 2 particularly suitable for large local music libraries, while NVMe storage provides fast access with silent operation. An SSD is not included.
HDMI ARC/Earc FOR HOME THEATRE
With HDMI ARC/eARC support, the DMP-A8 Master Edition Gen 2 can receive audio from compatible televisions and projectors and integrate it into a high-quality two-channel or distributed audio system.
This makes it equally relevant to dedicated listening rooms and premium home theatre environments.
20-Band Professional Eq & Dsp
The integrated 20-band parametric equalizer provides detailed control over frequency, gain and Q values.
Additional DSP functions include FIR filter support, loudness control and dynamic range compression, allowing the system to be adapted to room acoustics and individual listening preferences. The DSP adjustment range extends from approximately 3.51Hz to 20kHz.
8.6-Inch Touchscreen Control
A large 8.6-inch LCD touchscreen serves as the central interface for music browsing, playback and system control.
The redesigned user interface adds richer visual playback displays, including VU meters, spectrum analysis and multiple interface styles, while maintaining straightforward access to the music library and system functions.
Powerful Processing & Storage
A high-performance octa-core processor works with 8GB DDR5 memory and 64GB eMMC storage, providing fast system response and smooth operation.
The hardware platform is designed to handle large music libraries, streaming services, DSP processing and extensive connectivity without compromising everyday usability.
Control From Multiple Devices
The DMP-A8 Master Edition Gen 2 can be controlled directly from its touchscreen, through the Eversolo Control ecosystem and with the supplied dual-mode remote supporting Bluetooth and infrared operation.
Network control allows playback, input selection, volume, room correction and system settings to be managed conveniently from compatible devices.
Performance
The DMP-A8 Master Edition Gen 2 is engineered around exceptionally low noise and distortion figures:
-
THD+N: 0.000075% (-122dB) via XLR
-
XLR Dynamic Range: >129dB
-
XLR SNR: >129dB
-
XLR Crosstalk: >133dB
-
RCA THD+N: 0.000086% (-121dB)
-
RCA Dynamic Range: >127dB
-
RCA SNR: >127dB
-
RCA Crosstalk: >131dB
Specifications
-
Model: DMP-A8 Master Gen 2
-
Display: 8.6-inch LCD touchscreen
-
DAC: AK4499EXEQ + AK4191EQ
-
Audio Processor: Eversolo AuralEngine
-
Operational Amplifiers: OPA1612
-
Memory: 8GB DDR5
-
Internal Storage: 64GB eMMC
-
SSD Expansion: M.2 NVMe PCIe 3.0 2280, up to 8TB
-
Audio Clock: OCXO with PLL technology
-
External Clock: 10MHz input
-
Ethernet: RJ-45 Gigabit
-
Wi-Fi: Dual-band Wi-Fi 6, 2.4GHz + 5GHz
-
Bluetooth: Bluetooth 5.4
-
DAC Decoding: Up to DSD512 Native / PCM 768kHz 32-bit
-
USB-B Input: Up to DSD512 / PCM 768kHz 32-bit
-
USB Audio Output: Up to DSD512 Native / PCM 768kHz 32-bit
-
IIS Output: Up to DSD512 Native / PCM 768kHz 32-bit
-
Optical/Coaxial Input: Up to PCM 192kHz/24-bit and DSD64 DoP
-
AES/EBU Output: Up to PCM 192kHz/24-bit and DoP64
-
HDMI ARC/eARC: Up to PCM 192kHz/24-bit
-
Analog Input: XLR balanced + RCA pre-input
-
Analog Output: XLR balanced + RCA pre-output
-
Subwoofer Output: Dedicated SUB output
-
Power Supply: AC 100–240V, 50/60Hz
-
Rated Power: 30W
-
Dimensions: 388 × 265 × 98.5mm (W × D × H)
-
Net Weight: 6kg
-
Gross Weight: 8.45kg
In The Box
Why Buy From Soundtrails
The Eversolo DMP-A8 Master Edition Gen 2 is best understood as more than a streamer or DAC. It can become the digital and analog control centre of a serious high-end music system, combining streaming, local music, CD playback, digital conversion, analog preamplification and extensive system connectivity in one component.
At SoundTrails, our Audio Video Architects can help match the DMP-A8 Master Edition Gen 2 with the right power amplifier, speakers, subwoofer, network infrastructure and room configuration. From two-channel Hi-Fi to sophisticated home theatre and whole-home audio systems, we focus on system-level integration so that every component performs at its full potential.
