Discreet Bookshelf Speakers For Music & Home Theatre
is a compact passive bookshelf speaker system designed for music listening, desktop audio and home theatre applications. Featuring a 4-inch bass driver, a 19 mm silk-dome tweeter and an MDF cabinet, the P17 is designed to deliver clear high frequencies and balanced sound in a space-conscious enclosure.
Its integrated wall-mount brackets provide additional placement flexibility, making it suitable for bookshelf installations, desktop setups and surround speaker positions. As a passive speaker, it requires a compatible external amplifier or AV receiver.
Key Features
-
2-Way Speaker Design — Combines a dedicated bass driver and tweeter for a broad range of audio reproduction.
-
4-Inch Bass Driver — Designed to provide warmth and low-frequency support for music and films.
-
19 mm Silk-Dome Tweeter — Reproduces high frequencies with smooth, detailed treble.
-
MDF Cabinet Construction — Helps reduce cabinet vibration and unwanted resonance.
-
Integrated Wall-Mount Brackets — Supports flexible placement, including surround speaker applications.
-
Compact Design — Fits desks, bookshelves and smaller listening spaces.
Compact Design & Flexible Placement
The Edifier P17 is designed for listening spaces where a traditional floorstanding speaker may be impractical. Its compact enclosure allows it to fit alongside a desktop, on a bookshelf or within a home entertainment setup.
The integrated mounting brackets offer an alternative to shelf placement, allowing the speakers to be positioned on a suitable wall when the installation and mounting surface permit.
Balanced Acoustic Performance
The combination of a 4-inch bass driver and a 19 mm silk-dome tweeter is intended to reproduce low, mid and high frequencies through a compact two-way design. The published frequency response is 50 Hz–20 kHz.
For music playback, the P17 can be paired with a suitable stereo amplifier. In a home theatre system, it can also serve as a compact surround speaker, subject to appropriate amplifier matching and room placement.
Simple Amplifier Integration
The P17 is a passive speaker and does not contain its own power amplifier. Connect it to a compatible stereo amplifier or AV receiver using speaker cable.
Before installation, confirm amplifier compatibility, speaker placement and the required mounting hardware. The speaker's integrated brackets provide mounting flexibility, but the suitability of the wall and fasteners must be checked separately.
Technical Specifications
-
Model: P17
-
Product Type: Passive Bookshelf Speaker
-
Configuration: 2-Way
-
Bass Driver: 4-inch / 116 mm
-
Tweeter: 19 mm silk-film dome
-
Frequency Response: 50 Hz–20 kHz
-
Sensitivity: 77 dB (1 W/1 m), according to the published specification listing
-
Rated Power: 5–20 W, according to the published specification listing
-
Nominal Impedance: 6 Ω, according to the published specification listing
-
Crossover Frequency: 1,700 Hz, according to the published specification listing
-
Dimensions (W × H × D): 128 × 238 × 168 mm
-
Finish: Brown
In The Box
