XTZ Spirit 8 center speaker (Each)

Name: XTZ Spirit 8 center speaker (Each)
Brand: SoundTrails
Price: 51310.00 INR
Availability: InStock

Rs. 51,310.00

Color

In stock

SPIRIT 8

Spirit 8 is a perfect choice as a Centre Speaker in High Class Multichannel Setups. During the development, special attention was paid to vocal reproduction and an optimized dispersion pattern. Both factors are of fundamental importance for homogeneous and natural surround sound, as reproduction of the Human Voice is primarily projected via the Centre Channel. The optimization was done by adding a waveguide to the silk dome tweeter and by spending huge effort on the development of the high quality crossover. The customized drivers are unique spirit series and provide a matching acoustic balance and sonic signature throughout the Frequency range to highest dynamics and accuracy. Thus Spirit 8 is a key element for creating an immersive home cinema experience.

DRIVERS

The 25mm silk dome tweeter was customized for the Spirit-series and thus fits perfectly to the mid/bass drivers. Due to the waveguide technology, the dispersion pattern, as well as efficiency were optimized. The 6 1/2" mid/bass drivers originate also from the XTZ development center and provide precision, even at highest SPL. These High Quality Drive Units contribute to the excellent vocal reproduction, due to their outstanding stiffness-weight ratio, which is achieved by using a c-cone-sandwich membrane, enabling the mid/bass drivers to maintain control, even when at High Excursion, providing punchy and accurate bass.

SOUND TUNING

On the Rear Panel of the Spirit 8, there is a jumper, which allows adjustment of the tweeter output level to the prevailing room acoustics, or your personal preference. Furthermore, it is possible to close the bass reflex ports on the Rear Panel, with the attached plugs, which alter the Low Frequency characteristics of the speaker.

This enables placement of the speaker near a wall and drive it in sealed mode to compensate for the bass increase, due to the wall boundary effect.

SPECIFICATION

Construction Type: - 2-way Center-Speaker
Tweeter driver: - 1 x 25 mm (1") dome tweeter (Multi-coated in Waveguide design)
Midrange / Woofer driver: - 2 x 180 mm (6,5") Cocentric Dual Layer C-ABS cone driver (Cellulose fiber, acrylonitrile butadiene styren)
Frequency Response: - 42 - 22.000 Hz (+/- 3dB)
Nominal impedance: - 4 - 8 Ohm
Sensitivity: - 86 dB (2,83 V/1 m)
Power Handling: - 400 W Short term IEC 268-5, 180 W Long term IEC 268-5
Settings: - Bassreflex / Sealed (2 ports), Treble adjustable in 2 different modes
Crossover frequency: - 2.500 Hz
Filter steepness: - Midrange / Woofer driver: 12 dB, Tweeter: 24 dB
Dimensions: - 600 x 210 x 290 mm (W x H x D) /23.9 x 8.4 x 11.6"
Weight: - 14 kg / 31 lbs
