SPIRIT 4

The Spirit 4 is a very flexible and versatile bookshelf speaker, which can be either used as an excellent stereo setup, with pinpoint imaging and wide soundstage, or integrated into a thrilling surround system. As the Spirit 4 uses the same tweeter and mid/bass driver as the Spirit 11, sonically, it is a perfect match and able to perform with precision and accuracy. Despite the compact size of its cabinet, the deep bass qualities are astonishing. The implementation in a stereo system is recommended in rooms where powerful and dynamic sound is desired, but where there is not enough space for larger speakers.

DRIVERS

The 25mm silk dome tweeter was customized for the Spirit-series and thus fits perfectly to the mid/bass drivers. Due to the waveguide technology, the dispersion pattern, as well as efficiency were optimized. The Tweeter, which is used for Spirit 4 is a 25 mm silk dome which has been developed and adjusted especially for this application over years. It has been designed together with its waveguide to achieve a perfect match concerning precision and dynamics. The XTZ developed mid/bass driver, a customized long-stroke woofer is used which has proven its capabilities concerning the reproduction of deep yet articulate bass. It harmonizes perfectly with the tweeter, leading to a natural and balanced sound.

SOUND TUNING

On the Rear Panel of the Spirit 4, there is a jumper, which allows adjustment of the tweeter output level to the prevailing room acoustics, or your personal preference. Furthermore, it is possible to close the bass reflex port on the Rear Panel, with the attached plug, which alter the Low Frequency characteristics of the speaker.

This enables placement of the speaker near a wall and drive it in sealed mode to compensate for the bass increase, due to the wall boundary effect.

SPECIFICATION

Construction Type: - 2-way Bookshelf-Speaker
Tweeter driver: - 1 x 25 mm (1") dome tweeter (Multi-coated in Waveguide design)
Midrange / Woofer driver: - 1 x 180 mm (6,5") Cocentric Dual Layer C-ABS cone driver (Cellulose fiber, acrylonitrile butadiene styren)
Frequency Response: - 42 - 22.000 Hz (+/- 3dB)
Nominal impedance: - 4 - 8 Ohm
Sensitivity: - 86 dB (2,83 V/1 m)
Power Handling: - 200 W Short term IEC 268-5, 100 W Long term IEC 268-5
Settings: - Bassreflex / Sealed (1 port), Treble adjustable in 2 different modes
Crossover frequency: - 2.000 Hz
Filter steepness: - Midrange / Woofer driver: 12 dB, Tweeter: 18 dB
Dimensions: - 190 x 350 x 270 mm (W x H x D) / 7.5 x 13.8 x 10.6"
Weight: - 8.1 kg / 17.9 lbs

IN THE BOX

XTZ - Spirit 4 - Bookshelf Speaker (Pair)
Limited 1-Year Manufacturer Warranty
